Energy stored in an inductor By Uzma Noreen Group6 (part2)


Consider a coil connected to a battery and a switch is in series .when the switch is closed ,the current begins to follow.
V is the voltage across the ends of coil and current
through it rises from zero to max-value due to change of current ,an emf is induced,which is opposite to that of battery.
Work is done by the battery in moving a small charge Δq is given by

Δw= ΔqεL ...........(1)

More in Slides...
Attachment 2576


Presentation of the group 6 is divided into 3 parts on the bases of the Topic assigned to the group members
